AUMA SQ Part-Turn Actuator

Part-turn actuators, modular allrounders

AUMA SQ adalah electric part-turn actuator untuk open-close dan positioning duty (class A dan B, S2 - 15 min), torsi 50 s/d 2,400 Nm. Bisa dipadukan dengan actuator controls AUMA, dari OPEN-CLOSE sederhana hingga fieldbus interface.AUMA SQ adalah electric part-turn actuator seri SQ .2 untuk open-close dan positioning duty (class A dan B, short-time duty S2 - 15 min). Torsinya 50 s/d 2,400 Nm dengan swing angle standar 75° s/d 105°, cocok untuk butterfly valve, ball valve, dan plug valve. Seperti SA, SQ bisa dipadukan dengan actuator controls AUMA, dari OPEN-CLOSE controls sederhana hingga versi mikrokontroler dengan data logging dan fieldbus interface.

CHAT WHATSAPP LIHAT DOKUMEN

SPESIFIKASI UTAMA

TORQUE RANGE
50 s/d 2,400Nm
OPERATING TIME FOR 90°
4 s/d 100s
SWING ANGLE
75 s/d 105°
ENCLOSURE PROTECTION
IP68
CORROSION PROTECTION
KS
AMBIENT TEMPERATURE
-30 to +70°C

SPESIFIKASI LENGKAP

Spesifikasi Teknis AUMA SQ

Motor 3-phase AC, S2 - 15 min, class A dan B.Data untuk motor 3-phase AC, type of duty S2 - 15 min, class A dan B. Untuk motor 1-phase AC dan type of duty lain, lihat data sheet teknis terpisah dari AUMA.

Ukuran SQ untuk open-close duty

TYPE	OPERATING TIME [s]OPERATING TIMES 90° AT 50 Hz [s]	TRIPPING TORQUE [Nm]SETTING RANGE FOR TRIPPING TORQUE [Nm]	STARTS [1/h]STARTS MAX. [1/h]	FLANGE STD.FLANGE STANDARD (ISO 5211)	OPTIONFLANGE OPTION
SQ 05.2	4 s/d 32	50 s/d 150	60	F05/F07	F07, F10
SQ 07.2	4 s/d 32	100 s/d 300	60	F05/F07	F07, F10
SQ 10.2	8 s/d 63	200 s/d 600	60	F10	F12
SQ 12.2	16 s/d 63	400 s/d 1,200	60	F12	F10, F14, F16
SQ 14.2	24 s/d 100	800 s/d 2,400	60	F14	F16

Geser untuk melihat kolom lain

Sumber: Brosur AUMA “Electric actuators for industrial valve automation” (pb_modular_range_en), tabel SQ part-turn actuators for open-close duty (motor 3-phase AC, S2 - 15 min, class A dan B).

Detail SQ 05.2 s/d SQ 14.2 (3-phase AC)

FEATURES AND FUNCTIONS

Type of duty: Short-time duty S2 - 15 min, classes A and B according to EN ISO 22153
Motors: 3-phase AC asynchronous squirrel-cage motor, type IM B9 according to IEC 60034-7
Permissible variation of mains voltage: ±10 %
Insulation class: Standard: F, tropicalized. Option: H, tropicalized
Motor protection: Standard: Thermoswitches (NC). Option: PTC thermistors (according to DIN 44082)
Self-locking: Yes
Swing angle: Standard: adjustable between 75° and < 105°. Options: 15° to < 225° in several ranges
Manual operation: Handwheel for setting and emergency operation, does not rotate during electrical operation
Electrical connection: Standard: AUMA plug/socket connector with screw-type connection
Valve attachment: Dimensions according to EN ISO 5211 without spigot

SERVICE CONDITIONS

Use: Indoor and outdoor use permissible
Mounting position: Any position
Installation altitude: ≤ 2,000 m above sea level (> 2,000 m on request)
Ambient temperature: Standard: –30 °C to +70 °C. Options: –40 °C to +80 °C, –60 °C to +60 °C, 0 °C to +120 °C
Humidity: Up to 100 % relative humidity across the entire permissible temperature range
Enclosure protection (IEC 60529): Standard: IP68 with AUMA 3-phase AC motor. Option: double sealed terminal compartment
Corrosion protection: Standard: KS. Options: KX, KX-G (aluminium-free outer parts)
Coating: Double layer powder coating
Colour: Standard: AUMA silver-grey (similar to RAL 7037)

Sumber: AUMA Technical data SQ 05.2 s/d SQ 14.2, open-close duty, 3-phase AC (Y005.660/003/en, Issue 1.23).

FITUR

Fitur Utama AUMA SQ

Design features

Limit and torque sensing
Motor 3-phase AC dan 1-phase AC
Handwheel untuk operasi manual
Mechanical position indicator

Service conditions

Rentang suhu operasi yang lebar
Enclosure protection tertinggi
Corrosion protection berkualitas tinggi
Ambient temperature -30 °C to +70 °C

Interfaces

Electrical connection dengan AUMA plug/socket connector (terminal sebagai opsi)
Beragam versi cable entry
Valve attachment standar DIN dan ISO

Options

Intermediate position switches
Switches in tandem version
Position transmitter
Magnetic limit and torque transmitter
Base and lever untuk lever actuator
Functional safety s/d SIL 2 (SIL 3 dengan actuator controls AC 01.2 SIL)

Limit and torque sensing
Motor 3-phase AC dan 1-phase AC
Handwheel untuk operasi manual
Mechanical position indicator

APLIKASI

Area Aplikasi AUMA SQ

SQ mengotomasi valve seperempat putaran seperti butterfly valve, ball valve, dan plug valve. Pada open-close duty (class A) actuator menggerakkan valve dari buka penuh ke tutup penuh; pada positioning duty (class B) valve dibawa ke posisi tertentu termasuk posisi antara. Untuk modulating duty (class C), AUMA menyediakan seri SQR.
